Model No. |
CW19-1 |
CW19-2 |
CW19-3 |
Max. pull |
1,200 kgf |
3,000 kgf |
5,000 kgf |
Max. speed |
5 - 18 m/min |
5 - 18 m/min |
3.5 - 15 m/min |
Type |
Single Capstan with Hand band Brake |
Transmission |
Forward 4 step / Reverse 1 step |
Engine(gasoline) |
5 HP/2,000 r.p.m |
8 HP/1,800 r.p.m |
16 HP/3,600 r.p.m |
| Capstan dia. |
Ø 130 mm |
Ø 160 mm |
Ø280 mm |
| Dimensions(LxWxH) |
1,200x620x500 mm |
1,400x620x600 mm |
1,600x720x700 mm |
| Weight |
220 kg |
300 kg |
450 kg |
|
